E616 Series

Lightweight agricultural sprayer for long endurance missions and efficient crop cultivation.

Classic Folding Arms

The new product maintains the classic foldable body design, which is practical for logistics and transit.

Single Body
Strong And Durable

With the E-series product updates, the fuselage was reduced from dozens of original parts to a single entire body made of high-strength, impact-resistant materials through the adoption of a new one-piece molding method.

The fuselage was reduced from dozens of original parts to a single entire body.
The body incorporates a waterproof design that allows for washing.

Fully Waterproof Body

The body incorporates a waterproof design that allows for washing and the surface of the shell is painted bright blue, giving an eye-catching finish.

The new folding parts are made of one-piece injection molding.

New Folding Parts

The new folding parts are made of one-piece injection molding, making the structure more stable and durable. The unique C-shaped arm fixing clip design can effectively avoid problems such as swinging and sagging of the arm during handling.

A centralized power source with separate signal and power connections.

Integrated Power Supply Wiring

A centralized power source with separate signal and power connections to minimize interference.

E Series drone uses the conventional 10-16L tank.

Classic Tank

It uses the conventional 10-16L tank, which is the most popular and reliable load option available.

Reinforced Power Plug

In order to prevent the plug from getting in the way when changing the battery, the main power cord is routed out the side, and the battery interface is placed on the side of the landing bay. Additionally, the connectors are safer and more stable (optional AS150/AS150U plugs are available).

the main power cord is routed out the side, and the battery interface is placed on the side of the landing bay.
A removable camera adapter is installed in front of the frame.

Detachable Camera Mount

The front of the frame features a removable camera adapter that may be closed or fitted as needed.

Applications

Tech Specs

E Series

E616P

E620P

Motor

Hobbywing X8 / 8118

Propeller

28 - 32 inch

ESC

80A FOC

Supply Voltage

12S

Maximum Take-off Weight

36 kg

Wheelbase

1628 mm

Opening size

1720 * 1500 * 556 mm

Folding size

1073 * 956 * 546 mm

Tank capacity

16 L

Frame Weight

7 kg
